Brand:
|
Sinooutput
|
Model:
|
SINO-ME23
|
|
Engine:
|
23KW/1800rpm
|
Gearbox:
|
Ratio 1.88:1
|
|
Shaft length:
|
1200mm
|
Propller:
|
Bronze CU3, 4 blades dia 400mm
|
|
Boat length:
|
Max. 7.5m
|
Max speed:
|
15-17knots
|
|
Boat materials:
|
Suggest by Alu
|
Boat full loaded tonnage:
|
3.5ton
|
|
Application:
|
Life boat, working boat, patrol boat and other speed boat etc
|
Rated power:
|
23KW
|
|
Rated speed:
|
1800rpm
|
Power tolerance:
|
3
|
|
Idel speed:
|
750rpm
|
Cylinder number:
|
4
|
|
Type:
|
Inline
|
Bore*stroke:
|
89*92mm
|
|
Press ratio:
|
16.8
|
Displacement:
|
2.3L
|
|
Governing type:
|
Mechanical
|
Fire sequency:
|
1-3-4-2
|
|
Fuel consumption:
|
205g.kw/h
|
Voltage:
|
24V
|
|
Flyhweel size:
|
SAE3#11.5
|
Net weight:
|
330kg
|
|
Emission:
|
EURO2
|
Noise:
|
89dB(A)
|
|
Forward ratio:
|
1.88:1
|
|
Reverse ratio:
|
2.67:1
|
|
Input torque Mmax:
|
200Nm/ 150Nw
|
|
Power input Pmax:
|
55/40.8KW
|
|
Input speed Nmax:
|
4000rpm
|
|
Propeller thrust Fmax:
|
4000N
|
|
Dry weight:
|
18.5kg
|
|
Oil capacity:
|
0.75L
|
|
Oil grade:
|
ATF
|
